92 Keysight P937xA PXIe Service Guide
General Product Information
Error Terms
6-
Error Term Data
The error term descriptions in this section include the following information:
— a table of error terms
— description and significance of each error term
— measurements affected by each error term
— typical cause of failure for each error term
The same description applies to both the forward (F) and reverse (R) terms.
If Error Terms Seem Worse than Expected
To verify that the system still conforms to specifications, perform a system
verification. Refer to “System Verification” on page 36.
Data are listed here as a convenience only. Detailed instrument specifications are
in the Data Sheet, viewable online at
http://literature.cdn.keysight.com/litweb/5992-2765EN.pdf.
Table 6-1 Error Term Data
1
Frequency Range Directivity Source
match
Load match
Crosstalk
2
300 kHz to < 2 MHz 9 9 9 97
2 MHz to 1 GHz 21 19 21 95
> 1 to 2 GHz 21 20 19 123
> 2 to 4 GHz 21 20 15 121
> 4 to 6.5 GHz 20 15 11 121
> 6.5 to 9 GHz 11 11 9 119
> 9 to 14 GHz 9 9 7 110
> 14 to 20 GHz 4 6 6 98
> 20 to 24 GHz 3 5 4 82
1. The data in this table are uncorrected system performance. The values apply over an envi-
ronmental temperature range of 25 °C ±5 °C, with less than 1 °C deviation from the cali-
bration temperature.
2. All crosstalk values are typical.
