General Operating Information 2
Keysight U2020 X-Series User’s Guide 59
No. Function
1 Set the logarithmic (dBm) or linear (Watt) measurement unit for the currently selected measurement.
2 Set the measurement offset factor. The U2020 X-Series corrects every measurement by this factor to compensate for
the gain/loss.
3 Enable the relative mode, which computes the measurement result relative (as a ratio) to a reference value. When
enabled, the reference value can be set using the <Rel> control. The relative reading is displayed in either dB or %.
4 Enable the difference or ratio measurement, or disable all operations between feed 1 and feed 2.
5 Configure the gate and acquired measurement type for the feed.
