Keysight U2020 X Series - Trigger Functions

2 General Operating Information
56 Keysight U2020 X-Series User’s Guide
Trigger functions
1
4
2
3
5
6
7
8
9
10
No. Function
1
Set the single, free run, or continuous trigger mode. Select to enable trace and auto trigger delay for the single and
continuous trigger modes. For the free run mode, only auto trigger delay can be enabled.
2 Set the global trigger source to channel A or an external source.
