KFI SE25 - Winch Parts List

15
SE25
SE25 Specications
Winch Parts List
No. Part # Description Qty
1 MOTOR-25-BL Motor Assembly 1
2 250001-B Screw M6 x 20 – Black Zinc 4
3 250002-B Washer -Flat Φ6 6
4 250003-B Tie Bar – Black Flat 2
5 250004 Bushing Shaft 1
6 250005 Coupling Shaft 1
7 250083 Cross Screw M5 x 8 1
8 350200A-BF Steel Drum – Black Flat 1
9 SYN19-S50 Synthetic Cable 3/16” x 50’ 1
10 250008 Rear Bush Drum 1
11 250009 Front Thrust Washer 1
12 250010 Gear Ring Output 1
13 250300 Gear Carrier Assembly 1
14 250011 Retaining Ring Clip 1
15 250012 Spring 1
16 250013-BF Cover Clutch Housing - Black Flat 1
17 250014-B Cap Screw M6 x 70 – Black Zinc 2
18
GB2760BB1
6002-SS
Radial Ball Bearing 16002 Sealed 1
19 250016-BF Clutch Cap - Black Flat 1
20 250017-B Locking Washer Φ6 – Black Zinc 1
21 250018-B Cap Screw M6 x 16 – Black Zinc 1
22 250019 Axis Support Bushing 1
23
GB2760BB0
6002-SS
Radial Ball Bearing 6002 Sealed 1
24 250021 Clutch Bushing 1
25 250022 Above Clutch Axis Washer 1
26 250023 Cam Clutch Gear 1
27 250024-BF
Gear Housing / End Bearing -
Black Flat
1
28 250025 Gear Ring 1
29 250062 Wire Tap 1
30 250057 Winch Wires 2
31 250059-BF
Standard Roller Fairlead Bracket
- Black Flat
1
32 SE-RF
Roller Fairlead Black Flat & POM
Rollers
1
33 250030-B Hand Saver Strap - Black 1
34 ATV-CONT Contactor 1
35 ATV-MR Handle Bar Remote 1
No. Part # Description Qty
36 250032-B Hex Bolt M8 x 25 – Black Zinc 4
37 250063-B Locking Washer Φ8 – Black Zinc 4
38 250033-B Screw M10 x 20– Black Zinc 2
39 250035-B Locking Washer Φ 10– Black Zinc 2
40 250036-B Nut M10 – Black Zinc 2
41 250061 Terminal Protector 8
42 250045-BF
Handlebar Switch ClampBlack
Flat
2
43 250046-BF
Handlebar Switch Extender-Black
Flat
1
44 250047-BF
Handlebar Switch Mounting
Angle – Black Flat
1
45 250048-B Screw M5 x 25 – Black Zinc 4
46 250049-B Washer -Flat Φ5 – Black Zinc 5
47 250050-B Locking Washer Φ5– Black Zinc 3
48 250051-B Screw M5 x 18 – Black Zinc 1
49 250052-B Nut M5 –Black Zinc 3
50 250053-B Screw #6-32 x 9/32” –Black Zinc 2
51 250054-B Locking Washer #6 –Black Zinc 2
52 250058 Battery Wires 2
53 SE-HOOK Clevis Hook – Black E-coat 1
54 250065-B Screw M6 x 25 – Black Zinc 4
55 250066-B Washer -Flat Φ6 – Black Zinc 4
56 250067-B Locking Washer Φ6 – Black Zinc 4
57 250068-B Nut M6 – Black Zinc 4
58 250069-B Screw M6 x 1.0 x 20 – Black Zinc 2
59 250070-B Washer -Flat Φ8 – Black Zinc 8
60 250072 Gasket 1
61 ATV-SCHS Split Cable Hook Stopper 1
62 300024-B Hex Hd Bolt M8x20 – Black Zinc 4
63 SE-A-CAPKIT Motor Endcap w/ Brushes 1
64 250071 Motor Bushing 1
65 450028-B Bolt M8x30 - Black Zinc 4
