V. SET UP & USE OF YOUR WHEELCHAIR
A. Your Catalyst / Spark & It’s Parts
1. Push Handle Backrest Tube
2. Pneumatic Tire
3. Aluminum Handrim
4. Spokes
5. Rear Wheel Hub
6. Quick-Release Axle
7. Aluminum Wheel Rim
8. Anti-Tipper
9. Axle Plate
10. Rear Frame Component
11. Cross Brace
12. Caster Fork
13. Caster Wheel
14. Caster Housing
15. Flip-Up Composite Footrest
16. Swing-Away Latch Release
17. Swing-Away Footrest / Footrest
18. Lifting Strap
19. Seat Sling
20. Swing-Away Padded Armrest
21. Backrest
