V. SET UP & USE OF YOUR WHEELCHAIR
D. Swing-Away Armrests
1. Installation (Fig. 3)
a. Slide armrest into the tube of the receiver that is mounted on
rear side of frame.
2. Swinging Away
a. Lift armrest slightly so it is free of the receiver bolt. Rotate away
from the chair.
3. Removing Armrest
a. Lift armrest straight out of receiver.
DANGER: These arms offer only a lock against rotation and are designed to bear a downward
force only. They will remove completely if pulled up on and cannot be used to lift or otherwise
handle the chair. Failure to comply with the instructions above may result in the armrest
accidentally disconnecting from the wheelchair and result in a fall or loss of control and may cause
serious injury or death.
