V. SET UP & USE OF YOUR WHEELCHAIR
V. Spark - Folding Frame
1. Folding Frame
Before attempting to fold the frame, remove any seating system that is attached. Also, flip up or
remove any footplates.
a. Lift upwards on the strap (Fig. 36:A). This will disengage cross brace supports (Fig. 37:C)
from the seat hooks.
b. To reopen the frame, push down on one of the cross braces (Fig. 36:B) until the cross brace
supports (Fig. 37:C) have completely engaged with the seat hooks.
Fig. 37
C
Fig. 36
A
B
