22
IV. WHEELCHAIR USE & CONFIGURATION
I. Swing Away Armrests
WARNING: These arms offer only a lock against rotation and are designed to bear a
downward force only. They will remove completely if pulled up on and cannot be used to
lift or otherwise handle the chair. Failure to comply with the instructions above may result
in the armrest accidentally disconnecting from the wheelchair and result in a fall or loss of
control and may cause serious injury or death.
How to Use Your Armrest
1. Installation (Fig. 5)
a. Slide the armrest into the tube of the receiver that is mounted on the rear side of the frame.
2. Swinging the Arm
a. Lift the armrest slightly so it is free of the receiver bolt. Rotate away from the chair.
3. Removing the Armrest
a. Lift the armrest straight out of the receiver.
Fig. 5
