KI CATALYST 5 - Height Adjustable Flip Back T-Arm

23
IV. WHEELCHAIR USE & CONFIGURATION
J. Height Adjustable Flip Back T-Arm
WARNING: These arms offer only a lock against rotation and are designed to bear a
downward force only. They cannot be used to lift or otherwise handle the chair. Failure to
comply with the instructions above may result in the armrest accidentally disconnecting
from the wheelchair and result in a fall or loss of control and may cause serious injury or
death.
How to Use Your Armrest
1. Flipping the Armrest
The tension felt during the flipping of the armrest can be decreased or increased by tightening or
loosening the bolt (Fig. 6:B).
a. To flip back the armrest, pull the release lever (Fig. 6:A) up and lift the armrest assembly up
and back.
b. To return the armrest down, lower the armrest assembly until the release lever locks back
into place.
B
A
Fig. 6
