73
Maintenance
OYF072208/OTFS072001R
1. Engine coolant reservoir
2. Engine oil filler cap
3. Brake/Clutch* fluid reservoir
4. Air cleaner
5. Fuse box
6. Positive battery terminal
7. Negative battery terminal
8. Engine oil dipstick
9. Radiator cap
10. Windscreen washer fluid reservoir
11. Fuel filter*
* : if equipped
■■
Diesel Engine (1.7L)
❈ The actual engine room in the vehicle may differ from the illustration.
■■
Petrol Engine (Nu 2.0L)
