743
Maintenance
PARKING BRAKE
Checking the parking brake
Type A
Check whether the stroke is within specifi-
cation when the parking brake pedal is
depressed with 20 kg (44 lb, 196N) of
force. Also, the parking brake alone should
securely hold the vehicle on a fairly steep
grade.
If the stroke is more or less than speci-
fied, we recommend that the system be
serviced by an authorised Kia dealer.
Stroke : 4~5 notch
Type B
Check the stroke of the parking brake by
counting the number of “clicks’’ heard
whilst fully applying it from the released
position. Also, the parking brake alone
should securely hold the vehicle on a fairly
steep grade.
If the stroke is more or less than speci-
fied, we recommend that the system be
serviced by an authorised Kia dealer.
Stroke : 6~8 “clicks’’ at a force of 20 kg
(44 lbs, 196 N).
OTF050014/H
OTF050015R
■ Type B■ Type A
