749
Maintenance
2. Lift up the wiper blade clip. Then pull
down the blade assembly and remove it.
3. Install the blade assembly in the
reverse order of removal.
4. Return the wiper arm to the original
position.
Type B
1. Raise the wiper arm and turn the wiper
blade assembly to expose the plastic
locking clip.
2. Compress the clip and slide the blade
assembly downward.
3. Lift it off the arm.
4. Install the blade assembly in the
reverse order of removal.
OYF079061R
OHG070043/H
1LDA5023/H
CAUTION
Do not allow the wiper arm to fall
against the windscreen, since it
may chip or crack the windscreen.
1JBA7037/H
1JBA7038/H
