No. Fuse Name Fuse rating Protected component
1 GLOW 80A Glow Plug Relay
2 PTC HEATER #1 50A PTC Heater Relay #1
3 PTC HEATER #2 50A PTC Heater Relay #2
4 PTC HEATER #3 50A PTC Heater Relay #3
5 FUEL FILTER 30A Fuel Filter Relay
No. Relay Name Relay Type
1 Glow Plug Relay MINI PLUG
2 PTC Heater Relay #1 MINI PLUG
3 PTC Heater Relay #2 MINI PLUG
4 PTC Heater Relay #3 MINI PLUG
5 Fuel Filter Relay MINI PLUG
Engine compartment sub fuse panel (Diesel Engine)
Circuit
Relay Type
