CX.5-SERIES AMPLIFIERS
OWNER’S MANUAL
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Serial Number:
Model: CXA600.5
RMS Power, AMP1 and AMP2
@ 14.4V, 4Ω stereo, ≤ 1% THD+N
@ 14.4V, 2Ω stereo, ≤ 1% THD+N
@ 14.4V, 4Ω mono, ≤ 1% THD+N
40W x 4
75W x 4
150W x 2
RMS Power, SUB channel
@ 14.4V, 2Ω mono, ≤ 1.5 % THD+N
@ 14.4V, 4Ω mono, ≤ 1.5 % THD+N
300W x 1
150W x 1
Length [in, cm] 14, 30
Height [in, cm] 2-3/8, 6
Width [in, cm] 7-3/16, 18
Frequency Response [Hz] AMPS 1-2: 10–20k
SUB: 25–200
Signal-to-Noise Ratio [dB] >95dB, A-weighted, re: rated power
Input Sensitivity Low Level: 125mV–5V
High Level: 250mV–10V
Selectable Electronic Crossover HI, LO or OFF; Variable 50–200Hz @ 12dB/Octave
KickEQ™ Bass Boost Variable 0–12dB @ 40Hz
Subsonic Filter 24dB/Octave, Fixed @ 25Hz
Remote Bass: Yes [sold separately]
Pro Tip: To get the best performance from your new KICKER Amplifi er and extend the warranty by 1 year, use
genuine KICKER accessories and wiring.
MODEL: CXA600.5
WARNING: KICKER products are capable of producing sound levels that can permanently damage your hearing! Turning up a
system to a level that has audible distortion is more damaging to your ears than listening to an undistorted system at the same
volume level. The threshold of pain is always an indicator that the sound level is too loud and may permanently damage your
hearing. Please use common sense when controlling volume.
2016 CX 5-Channel Amp Rev C.indd 2 9/29/2015 4:03:31 PM
