5
2. Other Alarm Visual and Audible Indicators
Operational Mode Visual Indications Audible Indications Action/Note:
Normal (standby)
Green LED blinks approx every 60 sec.
Test (button press when no
alarm condition is present)
Green and amber LED’s illuminate.
Red LED blinks in sync with beep pattern.
• 4 loud pulses, a pause,
4 loud pulses.
• Single beep
Perform test button press once a
week to verify proper alarm operation.
CO Alarm Memory (unit has
experienced a CO alarm
event or 100 ppm or more CO
within the last 14 days)
Red LED blinks 1 time every 60 sec. None. Push button to clear Alarm Memory.
CO alarm reset
Red LED continues to signal the alarm
pattern.
After button push: CO alarm
pattern stops.
Unit is confi rming if CO is present or
if it experienced a nuisance situation.
Re-alarm means danger. Move to
fresh air and call 0800 111 999.
