Kidde GSA-REL - GSA-REL Fault Messages on Quickstart Panels

Chapter 4: Testing and troubleshooting
GSA-REL Technical Reference Manual 49
Device
Condition
LED
2-LCD message
Prerelease_1
Short
Trouble
Short Fault
Prerelease_1 [1]
Open
Trouble
Open Fault
Prerelease_1 [1]
Prerelease_2
Short
Trouble
Dev/Line Flt
Prerelease_2 [1]
Open
Trouble
Open Fault
Prerelease_2 [1]
Abort
Manual
Prerelease_1
Prerelease_2
Release_1
Release_2
No riser
Trouble
Dev/Line Flt
Device (Abort, Manual, Prerelease_1,
Prerelease_2, Release_1, or Release_2) [1]
Release_1
Short
Trouble
Short Fault
Release_1 [1]
Open
Trouble
Open Fault
Release_1 [1]
Release_2
Short
Trouble
Dev/Line Flt
Release_2 [1]
Open
Trouble
Open Fault
Release_2 [1]
[1] Message requires user programming
GSA-REL fault messages on QuickStart
panels
WARNING: Disconnect all wiring on TB4 of the GSA-REL (release circuits 1
and 2) when servicing the system. Disabling points does not prevent activation of
the release circuits. Failure to follow these instructions may result in loss of life,
serious injury, or property damage.
When programming is complete, the control panel resets itself and maps the line
controller card. During the reset, device supervision may cause the panel to
generate a common trouble message for each GSA-REL circuit. This is a normal
indication, and should clear within minutes. Table 20 lists other messages related
to the GSA-REL.
