Kidde K-RLCD-C User Manual

P/N 3102382-EN • REV 02 • ISS 15DEC16 13
Table 6: Controls and indicators for LCD remote annunciators (with and without common controls)
No.
Item Description
1
LCD display Displays system status, event messages, and event message details.
2
Up cursor button Scrolls up through the messages in the event message queue. Scrolls
up through characters for password entry.
3
Down cursor button Scrolls down through the messages in the event message queue.
Scrolls down through characters for password entry.
4
Enter button Displays message details for the current message. Enters the
password character selected.
5
Lamp Test LED-button Green LED that indicates the annunciator is energized.
Turns on all LEDs and displays a test pattern on the LCD. The test
runs for ten seconds. The LED next to the button indicates the lamp
test is running.
6
Drill LED-button Turns on all audible and common alarm output devices and, if
configured, all visible devices. Pressing the button again turns them
back off. The LED next to the button indicates the function is active.
Requires a password to operate.
Note: You must press and hold the button for 2 seconds to initiate a
drill.
7
Signal Silence LED-button Turns off (silences) all active audible and common alarm output
devices and, if configured, all visible devices. Pressing
the button again
turns them back on. The LED next to the button indicates the function
is active. Requires a password or the enable controls key to operate.
8
Reset LED-button Restores the system to the normal state, provided that no inputs are
latched in the active state. The LED next to the button indicates the
reset function is active. Requires a password or the enable controls
key to operate.
9
Ack/Silence LED-button Silences the panel buzzer and acknowledges all current events. The
LED next to the button indicates the function is active. Requires a
password or the enable controls key to operate.
Note: The password requirement may be disabled based on your
system configuration settings.
10
Controls Enabled LED Blue LED that indicates the controls in that group are enabled at the
annunciator. Enabling the controls requires a password or the enable
controls key.
11
Trouble LED Yellow LED that indicates an active trouble state (flashing = new
trouble event, steady = all current trouble events have been
acknowledged).
12
Ground Fault LED Yellow LED that indicates a ground fault somewhere in the system.
13
Supervisory LED Yellow LED that indicates an active supervisory state (flashing = new
supervisory event, steady = all current supervisory events have been
acknowledged).
14
Alarm LED Red LED that indicates an active alarm state (flashing = new alarm
event, steady = all current alarm events have been acknowledged).
15
Power LED Green LED that indicates the annunciator is energized.
