Example Event Message screen
Details screen
Pressing the Enter button while an event message is selected displays the Details screen. The system displays
this screen as long as you are pressing the Enter button or using the Up and Down cursor buttons. The system
returns to the Event Message screen after approximately 20 seconds of inactivity. You can also toggle between
the Event Message and Details screens by pressing and releasing the Enter button.
(1) Scrolling symbols: The symbols at the right of the screen title line show whether there are more detail
messages before or after the current message. Use the Up and Down cursor buttons to scroll through the
detail messages or devices in the zone. The up or down symbols disappear when you reach the start or end
of the list (or when there are no off-normal devices).
(2) Device address: The panel (P), card (C), and device number (D) that constitute the complete device address
for the device generating the event message.
(3) Device message lines: If programmed, the device message for the device that generated the event message.
This is usually a location description.
The Details screen provides details about the zone or device that generated the selected event message. If the
selected event message is for a zone, the Details screen shows which devices in the zone are active.
Example Details screen
13:47:00 A003 D000
001 ZONE ALARM ACT
East Wing Hallway
South Entrance
DETAILS
P:nn C:nn D:nnn
DEVICE MESSAGE LINE1
DEVICE MESSAGE LINE2
∨∧
(1)
(2)
(3)
DETAILS
P:01 C:01 D:001
East Wing Hallway
South Entrance
∨
