16 P/N 3102382-EN • REV 02 • ISS 15DEC16
Reading LCD displays
In addition to the system status LEDs, two annunciator models include an LCD display that can show the system
status, event messages, or event message details. The display can also be used to enter a password that
enables the common control buttons.
System Normal screen
The LCD display shows the System Normal screen when the control panel is in the normal (quiescent) state.
(1) Time and date: The system time in 24-hour format and the system date in MM/DD/YY or DD/MM/YY format,
depending on the market place.
(2) Banner lines: Your facility name (if programmed) and the message “System is Normal.”
Event Message screen
The LCD display shows the Event Message screen when the control panel enters the alarm, supervisory, monitor,
trouble, disablement, or test state. Use the Up and Down cursor buttons to scroll through the messages in the
queue.
(1) Time and points: The system time in 24-hour format, the number of active points (Annn), and the number of
disabled points (Dnnn) currently in the system.
(2) Event status: The event number (NNN), the event type (SSSSSSSSSS), and the event status (RRR). The
event number is the position of the event in the queue. The event type is alarm, supervisory, trouble, or
monitor. The event status is “Act” for active, or “Rst” for restored.
Note: The > symbol indicates the oldest, highest priority event. It is only visible when the K-R Series Remote
Annunciator is connected to a VM-1 panel with C-CPU firmware version 1.40.00 and above, and the system is
configured for the Canadian market.
(3) Event message: The first and second lines of the event message.
HH:MM:SS MM/DD/YY
Your Building
System is Normal
(1)
(2)
HH:MM:SS Annn Dnnn
NNN>SSSSSSSSSS RRR
MESSAGE LINE 1 XXXXX
MESSAGE LINE 2 XXXXX
(1)
(2)
(3)
