P/N 3102382-EN • REV 02 • ISS 15DEC16 15
Table 7: Controls and indicators for LED remote annunciator models with common controls, K-RLED24,
and K-RLED24R
No.
Item Description
1
Zone description label Zone or device description.
2
Active LED Red LED that indicates the zone or device is in the alarm state.
3
Trouble LED Yellow LED that indicates the zone or device is in the trouble state.
4
Supervisory zones The last four zones can be configured as alarm or supervisory. For
these zones, the top LED is a red/yellow bicolor LED. Red = alarm
event. Yellow = supervisory or monitor event.
5
Lamp Test LED-button Turns on all LEDs and displays a test pattern on the LCD. The test
runs for ten seconds. The LED next to the button indicates the lamp
test is running.
6
Drill LED-button Turns on all audible and common alarm output devices and, if
configured, all visible devices. Pressing the button again turns them
back off. The LED next to the button indicates the function is active.
Requires a password to operate.
Note: You must press and hold the button for 2 seconds to initiate a
drill.
7
Signal Silence LED-button Turns off (silences) all active audible and common alarm output
devices and, if configured, all visible devices. Pressing the button again
turns them back on. The LED next to the button indicates the function
is active. Requires a password or the enable controls key to operate.
8
Reset LED-button Restores the system to the normal state, provided that no inputs are
latched in the active state. The LED next to the button indicates the
reset function is active. Requires a password or the enable controls
key to operate.
9
Ack/Silence LED-button Silences the panel buzzer and acknowledges all current events. The
LED next to the button indicates the function is active. Requires a
password or the enable controls key to operate.
10
Controls Enabled LED Blue LED that indicates the controls in that group are enabled at the
annunciator. Enabling the controls requires a password or the enable
controls key.
11
Trouble LED Yellow LED that indicates an active trouble state (flashing = new
trouble event, steady = all current trouble events have been
acknowledged).
12
Ground Fault LED Yellow LED that indicates a ground fault somewhere in the system.
13
Supervisory LED Yellow LED that indicates an active supervisory state (flashing = new
supervisory event, steady = all current supervisory events have been
acknowledged).
14
Alarm LED Red LED that indicates an active alarm state (flashing = new alarm
event, steady = all current alarm events have been acknowledged).
15
Power LED Green LED that indicates the annunciator is energized.
