Kidde K-RLCD-C User Manual

2 P/N 3102382-EN • REV 02 • ISS 15DEC16
The annunciators and expanders can be mounted on a standard 4 in. square electrical box, using the included
mounting ring. They can also be surface mounted in locking steel enclosures.
The annunciators communicate with the FACP on the RS-485 data riser. This can be configured for Class A or
Class B communication. The annunciators do not provide ground fault isolation.
The annunciators are stand-alone units that can be powered by the FACP or by an approved power supply.
Models with common controls can use a separate, remote key switch to enable or disable the common controls.
Table 2: K-R Series models and accessories
Model number
Description
K
-RLCD Remote Annunciator: LCD text annunciator without common controls. English.
K
-RLCDF Remote Annunciator: LCD text annunciator without common controls. French.
K
-RLCD-R Remote Annunciator: LCD text annunciator without common controls. English. Red.
K
-RLCD-PG Remote Annunciator: LCD text annunciator without common controls. Portuguese.
K
-RLCD-SP Remote Annunciator: LCD text annunciator without common controls. Spanish.
K
-RLCD-C Remote Annunciator: LCD text annunciator with common controls. English.
K
-RLCD-CF Remote Annunciator: LCD text annunciator with common controls. French.
K
-RLCD-CR Remote Annunciator: LCD text annunciator with common controls. English. Red.
K
-RLCD-C-PG Remote Annunciator: LCD text annunciator with common controls. Portuguese.
K
-RLCD-C-SP Remote Annunciator: LCD text annunciator with common controls. Spanish.
K
-RLED-C Remote Annunciator: 16-pair LED zone annunciator with common controls. English.
K
-RLED-CF Remote Annunciator: 16-pair LED zone annunciator with common controls. French.
K
-RLED-CR Remote Annunciator: 16-
pair LED zone annunciator with common controls. English.
Red.
K
-RLED-C-PG Remote Annunciator: 16-pair LED zone annunciator with common controls.
Portuguese.
K
-RLED-C-SP Remote Annunciator: 16-pair LED zone annunciator with common controls. Spanish
.
K
-RLED24 Remote Expander: 24-pair LED zone expander with expander cable and zone card
insert.
K
-RLED24R Remote Expander: 24-pair LED zone expander with expander cable and zone card
insert. Red.
RA
-ENC1 One-position enclosure for Remote Annunciator.
RA
-ENC2 Two-position enclosure for Remote Annunciator and one Remote Expander,
including one interconnection cable.
RA
-ENC3 Three-position enclosure for Remote Annunciator and two Remote Expanders,
including two interconnection cables.
RKEY
Remote key switch on plate for enabling or disabling common controls
(Lock/Unlock).
RA
-LED16ZC Zone card insert for K-RLED-C, K-RLED-CR, and K-RLED-CF.
RA
-LED24ZC Zone card insert for K-RLED24, K-RLED24R.
