Kidde P4010ACLEDSCA User Manual

6. Installation / Mounting Instructions
• Figure3 illustrates interconnection wiring. Improper connection may
result in damage to the alarm, failure to operate, or a shock hazard.
• Makecertainalarmsarewiredtoacontinuous(non-switched)power
line. NOTE: Use standard CSA Listed household wire (as
required by local codes) available at all electrical supply stores
and most hardware stores.
• After selecting the proper location for your Smoke/CO Alarm, as
described in RECOMMENDED LOCATIONS, and wiring the AC Quick
Connect Harness as described in the WIRING INSTRUCTIONS (NOTE:
AC power should be turned off at this stage), attach the mounting
bracket to the electrical box. To ensure aesthetic alignment of the
alarm with the hallway, or wall, the “A” line on the mounting
bracket must be parallel with the hallway when ceiling mounted, or
horizontal when wall mounted.
Activating The Alarm
1. After installation of the mounting bracket, attach the
AC quick connect harness to the unit.
• If AC power is on at this time, the unit will chirp once to signal
that power has been applied, and a voice message will prompt
you to push the test button.
• If AC power is on at this time, confirm the green LED is on
constant.
2. Rotate the unit fully onto the mounting bracket, which will
automatically activate the backup battery.
• NOTE: Attaching AC power first, without using the mounting
bracket, will result in a low battery chirp, and voice message
“Low Battery. Pile Faible.” because the battery backup has
not been activated. Attach unit to mounting bracket very soon
after applying AC power to avoid false low battery notification.
• NOTE: The battery activation is a one-time feature. After
activation, the battery cannot be turned off, and can only
be deactivated at the end of product life. See Section 11:
Deactivation of Alarm.
The alarm is now activated! After installation/activation, test your
alarm as described in Operation and Testing section.
NOTE: The battery activation is a one-time feature. After activation,
the battery cannot be turned off, and can only be deactivated at
the end of product life. See Section 11: Deactivation of Alarm.
WARNING: Failure to properly install and activate this alarm
will prevent proper operation of this alarm and will prevent its
response to fire hazards.
