Chapter 3: Smoke control system programming
48 VM-1 Smoke Management Application Guide
Smoke control sequence
commands
Objective
9
Close supply air dampers to
remote zones on central system
Limit smoke spread
10
Close exhaust air dampers to
remote zones on central system
Limit smoke spread
11
Start central system supply fan (if
not currently on)
Pressurize adjacent zones
12
Start central system return fan (if
not currently on)
Create negative pressure in
smoke zone by exhausting
smoke
13
Reset the static pressure control
(if present) to maximum allowable
value for all systems under active
FSCS control
Monitoring and control
14
Monitor air flow and damper
position at panel
Confirms system operation
Note: Multiple central systems serving portions of a fire floor will
require sequencing for each central system command consistent with
smoke control application
Dual duct smoke control system
Table 16 lists the sequence for a dual duct smoke
control system.
Table 16: Dual duct smoke control
Smoke control sequence
commands
Objective
1
AUTO OFF Overrides HVAC system
2
Open central outside exhaust
damper
Reduce pressure
development in smoke zone
3
Open central outside supply
damper
Limit smoke spread
4
Close central return damper Limit smoke spread
5
Reset duct static pressure controls
to maximum design levels
Maximize air flow and
prevent duct collapse or
failure
6
Close smoke zone hot duct
damper
Isolate smoke development
7
Close smoke zone cold duct
damper
Isolate smoke development
8
Open smoke zone exhaust
damper
Reduce pressure
development
9
Close adjacent zone exhaust
dampers
Prepare zones for
pressurization and limit
smoke spread
Smoke control sequence
commands
Objective
10
Open fully adjacent zone hot duct
dampers
Prepare zones for
pressurization and limit
smoke spread
11
Open fully adjacent zone cold duct
dampers
Prepare zones for
pressurization and limit
smoke spread
12
Configure adjacent zone mixing
boxes for maximum air flow
Prepare zones for
pressurization and limit
smoke spread
13
Close hot dampers to remote
zones on dual duct system
Limit smoke spread
14
Close cold dampers to remote
zones on dual duct system
Limit smoke spread
15
Close exhaust air dampers to
remote zones on dual duct system
Limit smoke spread
16
Start central system supply fan (if
not currently on)
Pressurize adjacent zones
17
Start central system return fan (if
not currently on)
Create negative pressure in
smoke zone by exhausting
smoke
18
Monitor air flow and damper
position at panel
Confirms system operation
Note:
Multiple dual duct systems serving portions of a fire floor will
require sequencing for each dual duct system consistent with
smoke
control application.
Multi-zone smoke control
Table 17 lists the sequence for a multi-zone smoke
control system.
Table 17: Multi-zone smoke control
Smoke control sequence
commands
Objective
1
AUTO OFF Overrides HVAC controls
2
Open central multi-zone outside
exhaust outside dampers
Reduce pressure
development in smoke zone
3
Close central multi-zone return
damper
Limit smoke spread
4
Reset duct static pressure controls
to maximum design levels
Maximize air flow and
prevent duct collapse or
failure
5
Close smoke zone air supply
damper
Isolate smoke development
6
Open smoke zone air exhaust
damper
Reduce pressure
development
