SKP-BC32HL POWER CONTROLLER (E) CE
5
Model No
SKP-BC32HL
Input Voltage
AC 100-240V 50/60HZ
Output Voltage
DC 32V/ 20V 1.8A/3A
Power Consumption
60W
Counting Numbers
1-99
Counting Method
Count forward/Count down
Connecting Sensor
ON / OFF
Sensing Switch Mode
ON (2 Sensor) / OFF (1 Sensor)
Slow-Start Time Adj.
0.1-9.9 seconds
Slow-Start Speed Adj.
30％-100％ Rated speed
Start Detecting Time
0.01-9.99 seconds
Stop Detecting Time
0.1-9.9 seconds
Disqualification Detecting Alarm
On/ Off/FF/EF with LED Light and Buzzer
Qualification Detecting Alarm
On/Off/FF/EF with LED Light and Buzzer
Auto response/Manual response
ON/OFF
External Connection Input Confirm key/Reset Key
External Connection Output
OK / NG / OK ALL
Electric Screwdriver Speed Control
SPEED:HI/LO ；Slow Start
Size(mm)
150 *48*130(mm)
Weight(Kg) 0.9
Applicable Electric Screwdrivers
SKD-BC203L
SKD-BC207L
SKD-BC210L
SKD-BC512L ； SKD-BC512P
SKD-BC519L ； SKD-BC519P
SKD-BC512LF ； SKD-BC512PF
Accessories
Power cord*1
Suspension Bail *2
Terminal Block *1
※SKP-BC32HL must match with SIX PIN screwdrivers , please confirm the screwdriver’s type is SKD-BC
and connector is seven PIN when user is using it.
To confirm procedure of screwdriver:：
1、To confirm the sticker is “SKD-BC” type.
2、To confirm screwdriver’s CONNECTOR is SIX PIN.
3、To confirm the connect cable between Screwdriver and power controller is SIX wires.
3. Main Technical parameters
