3.3 Optional probes and cables
Reference Description Measuring range
Temperature and humidity probe
KTHA Interchangeable hygrometry and ambient temperature probe Hygrometry: from 0 to 100%RH
Temperature: from -20 to +70°C
KTHD Remote interchangeable hygrometry and temperature probe
NTC Temperature probe
KSI-50 / KSI-150 IP65 immersion probe From -40 to +120°C
KSA-150 Ambient use probe From -40 to +120°C
KSF-2 Wire probe From -20 to 100°C
KSPP-150 IP68 penetration probe From -40 to +120°C
KSP-150 IP65 penetration probe From -40 to +120°C
KCV-220 Probe with velcro From -20 to +90°C
Current and voltage input cables and pulse input cable
KCTD-10-B Voltage input cable 0-5 V or 0-10 V
KCCD-02-B Current input cable 0-20 mA or 4-20 mA
KCTD-I-B Pulse input cable
Maximal voltage: 5 V
Type of input: TTL frequency counting
Maximal frequency: 10 kHz
Maximum number of recordable
points: 20 000 points
Ammeter clamps
KPID-50-BRF
Ammeter clamp from 0 to 50 A, frequency range from 40 to
5000 Hz
From 0 to 50 A
AC
KPID-100-BRF
Ammeter clamp from 0 to 100 A, frequency range from 40 to
5000 Hz
From 1 to 100 A
AC
KPID-200-BRF
Ammeter clamp from 0 to 200 A, frequency range from 40 to
5000 Hz
From 1 to 200 A
AC
KPID-600-BRF
Ammeter clamp from 0 to 600 A, frequency range from 40 to
5000 Hz
From 1 to 600 A
AC
Relative pressure probe (water probe)
KSPE Relative pressure probe for liquids and gases (corrosive) From 0 to 10 bars
KSPE-2 Relative pressure probe for liquids and gases (corrosive) From 0 to 20 bars
Thermocouple probes
For more details about the available thermocouple probes, please see the ''Thermocouple probes'' datasheet.
For more details, please see the “Measuring probes for KISTOCK class 220” and “Thermocouple probes”
datasheets.
Connect a probe:
➢ Open the mini-DIN connection cap on the bottom of the KISTOCK.
➢ Connect the probe in such a way the mark on the probe is in front of the user.
Technical features 9
Mark
