GLYCOL PUMP
25
www.kimray.com
Repair Guide
ASSEMBLY
Place D slide on the plate. Use any oil to keep it in place
while inserting Pilot Piston Valve Housing (Fig 29.6).
Rotate it slightly to install the Pilot Piston Tubing
(Fig. 29.7).
Figure 29.6
Figure 29.7
Figure 29.8
