Kinco AX500 User Manual

Components Information
No.
Name
Description
①
Status Indicator
Status Indicator
The indicators on the display panel from top to bottom are PWR/RUN/ERR/BUS, specific
definitions are as follows:
Name
Sign
Status
Description
PWR
Power Indicator
Green
ON: Power On
RUN
Running Indicator
Green
ON: User Program
Startup
ERR
Error Indicator
Red
ON: User Program Fault
BUS
Communication Indicator
Red
ON: Communication
Fault
②
Network
3 Ethernet ports: EtherNet, EtherCAT A, and EtherCAT B. Provided in
the form of RJ45. Defult IP are as follows:
EtherNET: 192.168.1.100;
EtherCAT B: 192.168.2.100.
⑤
④
①
②
③
⑥
⑦
⑧

Kinco AX500 Specifications

General

Brand	Kinco
Model	AX500
Category	Controller
Language	English
