Kinco FV100 Series User Manual

Chapter 4 Wiring Guide of VFD
46
Chapter 4 Wiring Guide of VFD
4.1 Wiring and Configuration of Main circuit terminal
4.1.1 Terminal Type of Main Loop’s Input and Output
Table 4-1 Description of main loop terminal
Terminal name
Function description
L
、
N
Single phase 220VAC input terminal
R
、
S
、
T
3-phase 380V AC input terminal
○
一
DC negative bus output terminal
○
十
1、○
十
2
Reserved terminal for external DC reactor
○
十
2、○
一
External braking unit
B1
、
B2
Braking resistor terminal
U
、
V
、
W
3-phase AC output terminal
PE
Shield PE terminal
