Chapter 4 Wiring Guide of VFD
47
4.1.2 Wiring of VFD for Basic Operation
Fig.4-1 Basic wiring chart
4.2 Wiring and configuration of control circuit
4.2.1 Wiring of control circuit terminal.
Wire the terminals correctly before using the Drive. Refer to the table 4-2 for control circuit terminal function
Table 4-2 Control circuit terminal function
Sequence No.
Function
1
Analog input and output terminal, RS232 and RSRS485 communication port
Note
It is recommended to use cables bigger than 1mm2 to connect to the terminals.
J601 J602 J603 J604
I I I I
V V V V
AI1 AI2 AO1 AO2
