Kinco FV100 Series User Manual

Chapter 5 Operation Instructions of Kinco VFD
52
5.1.2Function Descriptions of LED and Indicators
The operation panel consists of a 5-digits eight segments LED display, 3 LED indicators for unit and 3 LED indicators for
status which is as shown in Fig.5-1. The LED display can display the status parameters, function codes and error codes of the
drive. The 3 unit indicators are corresponding to three units, the descriptions of three status indicator are shown in table 5-2
Table 5-2
Indicator
Status
Current status of drive
Operating status
indicator(RUN)
Off
Stop
On
Run
Operatingdirection
indicator(FWD)
Off
Forwards
On
Reverse
Operating mode
indicator(MON)
On
Controlled by operation
panel
Off
Controlled by terminals
Flashing
Communicating
5.1.3Display status of operation panel
FV100 operation panel can display the parameters in stopping, operating, editing and function code..
1. Parameters displayed in stopping status
When the drive is in stop status, the operation panel displays the stop status parameter. Pressing the SHIFT key can display
different stop status parameters in cycle (Defined by function code b4.05)
2. Parameters displayed in operation status
When the drive receives operating command, it starts running and its panel will display the operation status parameters, the
RUN indicator turns on. The status of FWD indicator depends on the operation direction. The unit indicator display the unit
of the parameter, by pressing the SHIFT key can display different operation parameters in cycle (Defined by function code
b4.05)
3. Parameters displayed in error status
When the drive detects a fault signal, the panel will display the flashing fault code..
Press the SHIFT key to display the stop status parameters and error code in cycle. By pressing the STOP/RST, control
terminal or communication command to reset the error. If the error exists still, then the panel keeps displaying the error code.
4. Parameter edit status
When the drive is in stop, operation or error state, press MENU/ESC can enter edit status(If password needed, please refer to
description of A0.00),. Edit state displays in 2-level menu, they are.function code group or function code number→function
code parameter value. You can press ENTER to enter parameter displayed status. In function parameter displayed status,
press ENTER to save the settings, and press MENU to exit the menu.
5.1.4Panel Operation
Various operations can be completed on the operation panel; the following are 5 common examples. Refer to function code
list in chapter 9 for detail function code description.
Example 1.Set parameters
