Kinco FV100 Series User Manual

Chapter 6 Troubleshooting
54
Chapter 6 Troubleshooting
Table 6-1 lists the possible faults of FV100, error code E001~E040. When VFD reports error, users could check this list and
record the detailed fault phenomena before seeking service from supplier.
Table 6-1 Faults
Error code
Error catagory
E001
Hardware or software over current during acceleration
E002
Hardware or software over current during deceleration.
E003
Hardware or software over current during running in constant speed.
E004
Hardware or software over voltage during acceleration.
E005
Hardware or software over voltage during deceleration.
E006
Hardware or software over voltage during running in constant speed.
E007
Input voltage is too high
E008
Input phase loss
E009
Output phase loss
E010
18.5kw below models.output current is detected too large; 22kw above models.IGBT module is
detected voltage drop too large.
E011
IGBT module’s heatsink overheat.
E012
Rectifer’s heatsink overheat.
E013
Running current is larger than VFD rated current for long time.
E014
Running current is larger than motor rated current for long time.
E015
External device fault.
E016
EEPROM W/R fault.
E017
VFD can not get communication with host.
E018
Power board/drive board/contactor damage causes contactor abnormal.
E019
Hall/drive board abnormal causes current detective circuit fault.
E020
Reserved
E021~E022
Reserved
E023
Keyboard parameter copy error
E024
Auto tunning fault in vector control.
E025
Encoder signal fault in lose-loop control
E026
VFD running current is detected smaller than set value of load lost.
E027
Braking unit fault.
E028~E032
Reserved
E033
VFD output is short circuit to earth
E034
VFD running speed and encoder detected speed deviation exceeds allowed value.
E035~E039
Reserved
E040
Extension card and control board SPI communication fault
Note.
VFD braking resistor short circuit may lead to VFD braking unit damage.
