Kinco-HP
User Manual
channels，So the addresses of its two channels in turn are %AIW0、%AIW2.
Channel Settings
Signal form ： Select the type of input signal for each channel. The sample values are
automatically converted linearly within the CPU，The data conversion format please refer to
3.3.2 Measurement Ranges and The measured value Representation
Filter way：Select software filters for each channel.
The measured value can be stabilized by using a filter for the rapidly
changing analog signal.
Note： If the system needs to respond quickly to an AI signal, the software
filter at that point should not be enabled.
The input sampling of software filter adopts sliding mode.The software filter has the following
options:
None --- Software filters are not enabled.
Arithmetic mean --- Take the arithmetic mean value of the signal sampling value.
Median average --- After the maximum and minimum values are removed from the
sample values, the remaining Numbers are averaged.
