7. Technical data QuickPresent air / Lite
18
* The scope of supply for QuickPresent Air Lite does not include batteries
Video inputs
Video input cable 3x HDMI type A connector with cable retractor, self-retracting, length: 0.85m
Video input WLAN 1x input for streaming the contents of smartphones, tablets via AirPlay, Miracast
WiFi frequency 2.4GHz/5GHz band automatic, IEEE 802.11n
Compatibility From Android 5 any iOS with Airplay support (iOS4.3 or higher)
Data encryption AES WPA PSK, WPA2 PSK
Video input resolution VESA, FullHD (2K/60Hz, 4/4/4), maximum resolution 4K/30Hz, 4/4/4
Video outputs
Wireless video output 1 x wireless 60GHz, virtually zero-latency transmission (<5 msec)
Video conformity Wireless HD version 1.1
Video resolution 480i / 576i to 1080p/60Hz 4:4:4; 4K/30Hz via local HDMI output
Video output resolution HDMI 1.4b/2.0; HDCP 1.4 / 2.2
Transmission range Up to 10m within a room in a direct line-of sight between transmitter and receiver,
devices facing each other. The antenna is located in the QuickPresent air below the logo,
and the main emission angle is oriented towards the terminal strip.
Further interfaces
HDMI-OUT 1x HDMI type A socket, for wired transmission to the playback device
AUDIO-OUT 1x 3.5mm jack
Features
Operation Touch-sensitive button with blue LED feedback for active input (“SHOW-me”)
Operation with battery*
Power bank 10,000mAh 3.85V, lithium-polymer battery, including management system
with various safety features
Operating time (fully charged) Approx. 7 hours (with 60GHz + active WLAN stick), approx. 14 hours without 60GHz
Charging time At least 4 hours
Battery status display LOGO backlight LEDs: Permanent red: < 30%; Flashing red: battery must soon be charged
Dimensions and weight
Sizes Transmitter: 22 x 6 cm (DxH) Receiver: 85 x 50 x 25 mm (LxWxH)
Weight (Lite version) Transmitter: 2.1 kg / Transmitter Lite version: 1.9 kg / Receiver: 0.4 kg
Temperature range
Operation 10 to +40°C
Storage 0 to +50°C
Air humidity 20% to 90% relative air humidity, not condensing
Voltage supply
Voltage QuickPresent air: 12 VDC 3A 60
GHz receiver: 5VDC 1.5A or 2A
Power consumption 12V DC max. 3A (Lite version 1.5A max.)
Power pack: primary 110 – 240VAC 50/60Hz, 1.3A max
