Nr. System status Description
1 Permanent white Normal operating condition, 60GHz transmitter and receiver are connected and
have established a video/audio connection.
2 Slowly flashes white (approx. 1sec) 60GHz transmitter is not connected or is switched o,
e.g. due to the missing video signal at the selected input.
3 Rapidly flashes white (approx.
1/5sec)
60GHz transmitter is being connected.
4 Dark / shortly flashes green STANDBY mode or switched o.
5 Permanent red* Battery status < 30%, remaining operating time approximately 1.5 hours
(depending on type of use).
6 Slowly flashes red* Batteries are almost empty / must be charged soon.
7 Shortly flashes blue,
then flashes white
The touch-sensitive button of the logo has been actuated:
the 60GHz transmitter is searching for new receivers.
2.1.1. LOGO backlight
The multi-colour backlight provides information on the current status of the 60GHz
transmission and is also used as battery status display*.
Remark:
No. 5 + 6 only apply to battery operation*.
Minimum recommendable charging time is approx. 4 hours.
The charging status is calculated from the operating time and the operating status of the wireless transmitter.
Attention:
In this context, only discharge is calculated! The actual charging status is not recorded.
Therefore, the device assumes with every charging cycle that the battery is full and calculates its discharge during use.
7
* The scope of supply for QuickPresent Air Lite does not include batteries
