3.3 STANDS ST-P11/600 & ST-P20/600
The drive PT 2500 E is designed for using with a stand. KINEMATICA recommends the
standard plate stand ST-P11/600 or the plate stand ST-P20/600 (double rod design).
According to the size of the working vessel a vessel holder may be used.
Description of the main components of the two stands:
stand ST-P11/600 stand ST-P20/600
Column(s) made of
stainless steel
boss head for
extension Ø13 mm
safety pos. ring
vessel holder
vessel holder
base plate
