Kinetico K5 Installation Instructions

K5 Installation Instructions
1
3 4
5 6
2
Install 3/8'' Water Supply
7
9
8
etihw
neerg
wolley
der
eulb
to blue
collet
To blue
collet
Cold water pipe run
wall mount using
bracket
under sink
test fit
Tap Mounting Preparation
Tap ConnectionsTap Installation
drill tap mounting hole Ø 13mm
consult with customer, choose one location
Tap Connection to Unit
Air Charge Ta nk Installation
Quickflo Ta nk Installation
(for Air Charge Tank
Installation, skip
to step 9)
tap
rubber gasket
mtg washer
washer
lock washer
nut
3/8'' FNPT
to
3/8'' quick connect
from white collet
etihw
neerg
wolley
der
eulb
to white
collet
etihw
neerg
wolley
der
eulb
to green
collet
to yellow
collet
yellow
green
etihw
neerg
wolley
der
eulb
insert blanking plug
(yellow collet)
green
to green
collet
Water Supply Connection
Unit Placement
OR
under sink
Connect 3/8” Supply pipe to
water mains via isolation valve
Installation should be in accordance with water
bylaws and plumbing regulations.
Minimum feedwater pressure 35psi (2.5 bar)
10
Drain Installation
etihw
neerg
wolley
der
eulb
to red
collet
air gap
turn clockwise
until stops
DO NOT
OVER
TIGHTEN
use ''A'' spacer
(gray)

Kinetico K5 Specifications

General

Filter Type	Reverse Osmosis
Daily Production Rate	50 gallons per day
Certifications	NSF/ANSI 58
Filter Life	6-12 months
Waste Water Ratio	1:1
