3.5.2 – Securing the gear motor to the
fixing brackets
• Secure the gear motor to the rear bracket:
01.SecurethegearmotortothebracketasshowninFig. 7 using
thescrews,washersandnutssupplied;
Fig. 7
02.Fullytightenthenutstothescrews.
• Install the arms onto the motor:
01.Securethearmontothegearmotorusingthescrew;
Fig. 8
02.FixthetwoarmstoeachotherusingthepinandthesegerFig. 9;
Fig. 9
• Secure the gear motor to the front bracket:
01.SecurethegearmotorarmtothebracketasshowninFig. 10
usingthepinandsegersupplied;
Fig. 10
02.Tightenthesegerfullyontothepinseat;
3.5.3 – Installation of the front fixing
bracket
01.Thefrontbracketmustbesecuredtogateleaf;
02.DenethefrontbracketpositionheightinaccordancewithFig. 4;
03.FixthebrackettothesolidsectionofthegateleafFig.11.
Fig. 11
3.5.4 – Installation and adjustment of
the motor limit switches
Adjustthegearmotoropening and closinglimitswitches:
01.ReleasethegearmotorasshowninFig. 12;
Fig. 12
