The KA
285
Annunciator Panel annunciates
all vertical and lateral Flight DirectorlAuto-
pilot system modes, including all “armed”
modes prior to capture. It tells the pilot when
his selected mode has been received and ac-
cepted by the system and
if
an “armed” mode
is selected when capture has been initiated It
also has integral marker beacon lights and
trim failure warning
Pitch and roll commands
displays constantly slaved gyro magnetic
heading information, along with VORILOCI
RNAV course deviation and Glideslope de-
Controller when the optional yaw (rudder)
axis is included in the KFC
200
system The
yaw axis is wired
so
that it automatically en-
gages when the Autopilot is engaged Dis-
FD
NAV ARM ALT AP
7
HDG APPR CPLD
E
GA
60
YAW
DAMP
21
