Page 25
6. Run coax from the antenna unit to the roof edge, then along edge to location where coax will be
fed into the vehicle. If installing an optional second receiver, run second coax to location where it
will enter the vehicle. Secure (both) coax to roof every 12-18 inches (see below).
7. Drill 3/4” hole through the roof and into the cabinet where receiver is stored. Feed coax down
through hole. Seal opening with roof compatible sealant so that it is completely waterproof
(inside and outside of the 3/4” hole). Repeat for second coax if present.
8. Inside vehicle, make connections as shown in section 4, CONNECTIONS.
IMPORTANT!
Roof hole(s) for wiring must be sealed
so they are completely waterproof.
Sealant must be roof compatible.
IMPORTANT!
You can cut the coax
to length but you must
terminate the coax with
Snap-n-Seal Connectors.
