Page 21
6. Run coax from the antenna unit to the roof edge, then along edge to location where coax will
be fed into the vehicle. If installing an optional second receiver, run second coax to location
where it will enter the vehicle. Secure (both) coax to roof every 12-18 inches (see below).
7. Drill 3/4” hole through the roof and into the cabinet where receiver is stored. Feed coax down
through hole. Seal opening with roof compatible sealant so that it is completely waterproof
(inside and outside of the 3/4” hole). Repeat for second coax if present.
8. Inside vehicle, connect coax cable(s) to the appropriate receiver(s).
9. Go to KING TAILGATER OPERATION Section.
IMPORTANT!
Roof hole(s) for wiring must be sealed
so they are completely waterproof.
Sealant must be roof compatible.
IMPORTANT!
You can cut the coax
to length but you must
terminate the coax with
Snap-n-Seal Connectors.
