Kingfisher FPCSP46-2 - Page 18

18
FPCSP46-2
Getting Started . . .
1. Pull the front hand guard (4) backwards to disengage the chain brake (Fig. 1).
4
1
2. Unscrew the xing nuts (18) using the multi-tool (24) and remove them together
with the clutch cover (17) (Fig. 2).
Ensure the spiked bumper (21) is properly xed to the product. Tighten the screws
if necessary.
2
18
24
17
21
Before you start
