5. Leveling 6. Vibration compensation
1110
12864 display screen: Click on Level, Z_ Offset, Probe, wait for the
extrusion head to move to the middle of the hot bed. Use the Probe
to adjust up and down, adjust the distance between the nozzle and
0.1mm, and click Save to save after the adjustment is completed.
Then click on Auto_ Perform 36 point automatic leveling at level.
Step 7Jobs option, print Pressure Advance Calibration, wait for
pressure advance calibrationAfter printing, observe the most
complete line, and the value on the right is the pressure advance
number.
Step 8Open MKS in the configuration file_ THR.cfg, modify the
pressure in line 45_ AdvantageAdvance the pressure data, then
save and restart it in the upper right corner. It is recommended to
perform the following steps every time the consumables are
replacedPerform a pressure pre calibration once.
Step 5
Preheat the extruder and load the filament.On the webpage side: Macros
option, click on the preheating function, wait for the printer to automatically
return to zero before loading the high-speed printing filament. Please pass the
high-speed printing filament through the filament exhaust sensor and then feed
it into the extruder.Tool option, change the Extrude Length to 100mm, and then
click EXTRUDE,Wait for the nozzle to have filament extrusion.
3.5 Touch screen: Click on Actions, Extract, Temperature, PLA,
wait for the temperature to reach the target temperature, and
extrude a 100mm filament.
Step 6
Macros option, click on the vibration compensation shaper, and wait
for the vibration frequency data.Note: During the vibration
compensation process, the printer will generate vibration noise in the
vibration compensation shaper.
