Kioti CS2220H - Checking ENGINE Oil Level (E)

7
-
10
CS2220H(S)/CS2520H(S)
M46O706A
(1) Oil Dipstick
(A) Upper Limit (B) Lower Limit
5. Pull out the oil dipstick, clean it,
and then insert it into its original
position. Then, pull it out again and
check if the oil level is within the
specied range.
6. If the oil level is too low, add some
new oil so that the level is within
the allowable range. (Refer to
"Replacing transmission fluid and
lter" in the chapter "Service")

If oil level is low, do not run en-
gine.

Never add the oil over the up-
per limit.
IMPORTANT
tb2O701A
CHECKING ENGINE OIL LEVEL
(E)
(1) Oil Inlet Plug (2) Gauge
(A) Oil level is acceptable within this range
