IMPLEMENT LIMITATIONS
STANDARD IMPLEMENT DIMENSIONS
This KIOTI tractor has been thoroughly tested for proper performance with implements sold or approved by KIOTI. Use
with implements which are not sold or approved by KIOTI and which exceed the maximum specications listed below,
or which are otherwise unt for use with this KIOTI tractor may result in malfunctions or failures to the tractor, damage
to other property and injury to the operator or others. [Any malfunctions or failures to the tractor resulting from use with
improper implements are not covered by the warranty.]
NOTE : Implement size may vary depending on soil operating conditions.
Item
Model
Tread (max. width)
Lifting Capacity max.
loading weight W
0
(24 in. aft of hitch)
Front Rear
ALL 930 mm (36.6 in.) 870 mm (34.3 in.) 318 kg (701 lbs.)
Item
Model
Actual gures
Trailer loading weight
W
3
Max. capacity
Implement weight W
1
and /
or size
Max. Drawbar Load W
2
ALL
As in the following list
(shown on the next page)
310 kg (683 lbs.) 2,000 kg (4,409 lbs.)
Lifting Capacity max. loading weight ............. The max. allowable load which can be put on the 24 in. aft of hitch : W
0
Implement weight ..........................................The implement's weight which can be put on the lower link : W
1
Max. drawbar load ......................................... W
2
Trailer loading weight ....................................The max. loading weight for trailer (without trailer's weight) : W
3
S42O301A
