(1) Reserve Tank
(A) FULL (B) LOW
1. Check to see that the coolant level
is between the "FULL" and "LOW"
marks of recovery tank.
2. When the coolant level drops due
to evaporation, add water only up
to the full level.
In case of leakage, add anti-freeze
and water in the specied mixing ra-
tio up to the FULL level. (See "Flush
Cooling System and Changing Cool-
ant" in every 2 years maintenance)
CHECKING COOLANT LEVEL (F)
3. The tractor is furnished with a mix-
ture of anti-freeze and water in a
ratio of 50:50 which is usable in
any season.
tb3O701A
(1) Radiator Screen (2) Bolt
(A) Detach
CLEANING GRILL, RADIATOR
SCREEN (G)
To avoid accidents:
Be sure to stop the engine be-
fore removing the screen.
CAUTION
1. Check front grill and side screens
to be sure they are clean of debris.
2. Unscrew the bolt, lift out the radia-
tor screen and remove all the for-
eign material.
tb3O702A
