6-22 DK35/40/450L
PRECAUTION AT OVERHEATING
Take the following actions in the event
the coolant temperature be nearly or
more than the boiling point, what is called
“Overheating”.
1. Stop the machine operation in a safe
place and keep the engine unloaded
idling.
2. Don’t stop the engine suddenly, but
stop it after about 5 minutes of un-
loaded idling.
3. Keep yourself well away from the
machine for further 10 minutes or while
the steam blown out.
4. Checking that there is no danger of
burn, get rid of the causes of over-
heating according to the manual, see
“Troubleshooting” section, and then,
start the engine again .
615O633A
(1) Power Steering Oil Line
1. Check to see that all hydraulic lines
and hose clamps are tight and
undamaged.
2. If damage is found you should replace
the hose or clamp at once.
POWER STEERING LINE
615O634A
(1) Wheel - to - wheel distance at front (A)
(2) Wheel - to - wheel distance at rear (B)
ADJUSTING TOE-IN
When you have adjusted toe-in wrong,
you can feel abnormal vibration from the
steering wheel.
You should measure the front (A) and
rear (B) of the front wheel, and confirm
that (B)-(A) = 8 ~ 10mm (0.31 ~ 0.39in)
ADJUSTING PROCEDURE
1. Loosen the lock nut and turn the turn-
buckle to adjust the rod length until the
proper toe-in measurement is obtained.
2. Retighten the lock nut.
