1-4 DK35/40/450L
615O106A
615O107A
A ROPS should never be modified by
welding, grinding or cutting, as this can
weaken the ROPS structure. If any com-
ponents of the ROPS unit is damaged, it
must be replaced.
If the ROPS unit is removed or loosened
for any reason, the parts should be fit-
ted back to their original positions and all
bolts should be properly torqued.
NOTE
Always use seat belt when the trac-
tor is equipped with a ROPS. Never
use the seat belt when tractor is not
equipped with a ROPS.
(ROPS: Roll-Over Protective Structures)
21.Extra caution should be taken when
driving tractors with narrow tread
widths. For added stability you should
adjust your rear wheel tread width,
see page 8-3.
19.Before starting your tractor you
should disengage the clutch, and
make sure that all shift levers are in
the neutral position.
20.For your safety ROPS with a seat belt
is recommended for most applications.
(1) Max. tread width (2) Rear wheels
