ENGINE COOLANT TEMPERATURE GAUGE
Tf1O409A
(1) Coolant Temperature Gauge
(2) Normal Temperature Range
"C" : Cold "H" : Hot
This gauge indicates the coolant
temperature after the key switch is
turned to the "ON" position.
C : Coolant is cold.
H : Coolant is hot.
The range marked in "2" in the gure
indicates the normal engine tempera-
ture (Normal driving range).
CAUTION
Make sure to control the work
load so that the needle is not
in the red zone.
IF THE NEEDLE STAYS IN THE
RED Z ONE , D O N OT STOP
THE ENGINE IMMEDIATELY.
I N S T E A D , R E D U C E T H E
WORK LOAD TO COOL DOWN
THE ENGINE BEFORE STOP-
PING THE ENGINE.
Make sure to keep the front
grill clean so that air is sucked
through if freely for fast cooling.
•
•
•
TURN SIGNAL LAMP
Operating the turn signal lamp switch
up and down turns on the corre-
sponding lamp in green.
Tf1O410A
