Chapter 1 Before Use 1-5
1. 4 Specifications
Subject Specification
Model KIP 7900
Configuration Console
Printing method Electro photography
Photoconductor Organic Photoconductive Drum
Print speed 160mm per second
Print head LED
Resolution 600dpi
Print width Maximum 36” (914mm)
Minimum Roll: 11” / 297mm
Cut sheet (Portrait): 8.5” / 210mm
Print length Maximum
(Standard) 6m (bond, 36” / A0 wide only)
or “5 x Standard length” (bond)
“2 x Standard length” (vellum)
“1 x Standard length” (film)
(Option) 24m or Unlimited
Minimum 8.5” (210mm)
NOTE: If the print is longer than the maximum listed above, its
image quality or the reliability of paper feeding is not
guaranteed.
Warm up time Less than 6 minutes
(23 C / 74F, 60% RH and the rated voltage on Bond)
First print time 15.5 seconds (E from Roll 1)
Fusing method Roll Fuser
Development method Dry type with non-magnetic mono-component toner
Exposure method LED
Charging method Corona
Transfer method Corona
Separation method Corona
Input power 220V - 240V , 50/60Hz, 15A
Power consumption Maximum 3,600w
Stand by 1.3kwh (Average)
Printing 2.5kwh (Average)
Cold sleep 14w or less
230V, 50/60Hz and Dehumidify Heater is ON
Acoustic noise less than 67db (Printing)
less than 55db (Standby)
Ozone less than 0.1ppm (Average)
Dimensions 1370mm (W) x 700mm (D) x 965mm (H) (w/o UI) 54” x 28” x 38”
1385mm (W) x 820mm (D) x 1590mm (H) (w/ UI) 55” x 33” x 63”
Weight Approx. 386 kg 851 lbs
Media (Recommended Media)
Plain Paper US Bond (PB-20)
Tracing Paper US Vellum (XV-20)
Film 4MIL (PF-4DME)
Environmental condition
for usage
Temperature: 10 to 32 C 50 to 90 F
Humidity: 15 to 85% RH
Interface Ethernet (10 BASE-T, 100 BASE-TX, 1000 Base-T)
(continued on the next page)
