Chapter 2 Basic Operations 2-17
2. 5 Placing Cut Sheet Media
1. Open Manual Table.
2. There are several size markings on Manual Table which indicate possible feed positions.
Place a cut sheet in a required size on the table between its concerning size markings then
insert it into Manual Feeder.
When the leading edge touches the feeding roller, the machine automatically carries and sets
the sheet at the proper position.
NOTE
As a curly cut sheet will cause a mis-feed, straighten the sheet as far as possible before
printing. And set the sheet in “curl down” direction as a mis-feed can be avoided. “Curl up”
sheets tend to result in a mis-feed.
Correct (curl down) Wrong (curl up)
Manual Table
OK NG
Size Markings
Manual Table
To Next Page
